مادربرد ایسوس مدل TUF GAMING Z790-PLUS WIFI D5

کد محصول: 90MB18V0-M1EAY1
تومان 18,500,000

این مادربرد که از سری مادربردهای گیمینگ اما اقتصادی ایسوس است با چیپست پردازنده Z790 و سوکت پردازنده LGA1700 اینتل میتواند به راحتی از پردازنده های نسل 13و12 اینتل پشتیبانی کند و با 4 اسلات DDR5 تا 192 گیگ قابلیت پشتیبانی از رم های پرسرعت را دارد.

ATX

Intel Z790

Intel LGA 1700

RAM Slot x 4

برند :

مشخصات فیزیکی

  • ابعاد

    244×305 میلیمتر

  • فرم فاکتور

    ATX

پردازنده و چیپ ست

  • تعداد سوکت پردازنده

    1 عدد

  • نوع سوکت پردازنده

    Intel LGA 1700

  • چیپ‌ست

    Z790

  • برد تغذیه

    16+1 فاز

  • پردازنده های پشتیبانی شده

    13th Gen Intel Core , Pentium gold and Celeron Processors

  • پشتیبانی از RAID

    NVMe RAID 0/ 1/ 5

    SATA RAID 0/ 1/ 5/ 10



حافظه رم

  • تعداد اسلات حافظه

    4 عدد

  • پیکربندی حافظه

    دو کاناله

  • حداکثر حافظه پشتیبانی شده

    192GB

  • استانداردهای حافظه

    DDR5 7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/ 5200/ 5000/ 4800

  • پروفایل حافظه XMP

    دارد

  • پروفایل حافظه AMP

    ندارد

  • توضیحات حافظه

    Non-ECC, Un-buffered Memory*

    Dual Channel Memory Architecture

    Supports Intel® Extreme Memory Profile (XMP)

    OptiMem II

    *Actual Memory frequency support depends on the CPU types and DRAM modules, for more information refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).



کارت گرافیک

  • اسلات PCI Express x16

    2 عدد

  • تعداد مسیرهای PCI Express

    4 عدد

  • سایر توضیحات کارت گرافیک

    Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.

    ** Supports max. [email protected] as specified in DisplayPort 1.4

    ***Supports [email protected] as specified in HDMI 2.1.

    **** VGA resolution support depends on processors' or graphic cards' resolution.



اتصالات داخلی

  • اسلات PCI

    2 عدد

  • کانکتور M.2

    4 عدد

  • نوع اسلات M.2

    Key M

  • مجموع کانکتور فن

    7 عدد

  • کانکتورهای برق

    1x 24-pin Main Power connector
    2x 8-pin +12V Power connectors

  • سایر توضیحات مربوط به اسلات‌ها

    1x PCIe 5.0 x16 slot
    1x PCIe 4.0 x16 slot (supports x4 mode)
    1x PCIe 4.0 x4 slot
    2x PCIe 3.0 x1 slots

  • هدر USB 2.0

    2 عدد

  • هدر USB 3.2

    2 عدد

  • تعداد هدر USB 3.2 Type-C

    1 عدد

  • کانکتور SATA 6.0

    4 عدد

پنل پشتی

  • پورت PS/2

    ندارد

  • پورت USB 3.2 Gen 1

    4 عدد

  • پورت USB 3.2 Gen 2

    3 عدد

  • پورت HDMI

    1 عدد

  • پورت DisplayPort

    1 عدد

  • پورت LAN

    دارد

  • کارت شبکه LAN

    Intel® 2.5Gb Ethernet

    TUF LANGuard



  • کارت شبکه WLAN

    2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)

    Supports 2.4/5GHz frequency band



  • بلوتوث

    Bluetooth v5.3

  • کارت صدا

    Realtek S1220A 7.1 Surround Sound High Definition Audio CODEC

  • کانال‌های صوتی

    7.1 کانال

  • جک 3.5 میلی‌متری

    5 عدد

  • خروجی صدای S/PDIF

    دارد

  • توضیحات کارت صدا

    - Impedance sense for front and rear headphone outputs
    - Internal audio Amplifier to enhance the highest quality sound for headphone and speakers
    - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
    - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in)
    - Supports up to 32-Bit/192 kHz playback*"
    Audio Features
    - Audio Shielding
    - Rear optical S/PDIF out port
    - Premium audio capacitors
    - Dedicated audio PCB layers
    - Audio Cover
    * Due to limitations in HDA bandwidth, 32-Bit/192 kHz is not supported for 7.1 Surround Sound audio

  • توضیحات تکمیلی تمامی پورت‌های USB مادربرد

    Rear USB (Total 8 ports)
    1x USB 3.2 Gen 2x2 port (1 x USB Type-C®)
    3x USB 3.2 Gen 2 ports (2 x Type-A + 1 x USB Type-C®)
    4x USB 3.2 Gen 1 ports (4 x Type-A)
    Front USB (Total 7 ports)
    1x USB 3.2 Gen 2 connector (supports USB Type-C®)
    1x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports
    2x USB 2.0 headers support additional 4 USB 2.0 ports

  • توضیحات تکمیلی پورت‌ها

    1x USB 3.2 Gen 2x2 port (1 x USB Type-C®)
    3x USB 3.2 Gen 2 ports (2 x Type-A + 1 x USB Type-C®)
    4x USB 3.2 Gen 1 ports (4 x Type-A)
    1x DisplayPort
    1x HDMI® port
    1x Wi-Fi Module
    1x Intel® 2.5Gb Ethernet port
    5x Audio jacks
    1x Optical S/PDIF out port

سایر مشخصات

  • نقاط کنترل ولتاژ

    دارد

  • ویژگی‌های خاص

    ASUS TUF PROTECTION
    - DIGI+ VRM (- Digital power design with DrMOS)
    - ESD Guards
    - TUF LANGuard
    - Overvoltage Protection
    - Safeslot
    - Stainless-Steel Back I/O
    ASUS Q-Design
    - M.2 Q-Latch
    - PCIe Slot Q-Release
    - Q-DIMM
    - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
    - Q-Slot
    ASUS Thermal Solution
    - M.2 heatsink
    - VRM heatsink design
    ASUS EZ DIY
    - CPU Socket lever protector
    - ProCool
    - Pre-mounted I/O shield
    - SafeDIMM
    AURA Sync
    - Aura RGB header
    - Addressable Gen 2 headers

  • اقلام همراه

    Cables
    2x SATA 6Gb/s cables
    Miscellaneous
    1x ASUS Wi-Fi moving antenna
    1x TUF GAMING sticker
    2x M.2 Rubber Packages
    1x Screw package for M.2 SSD
    Documentation
    1x TUF Certification card
    1x User guide

  • مشخصات تکمیلی

    ASUS Exclusive Software
    Armoury Crate
    - Aura Creator
    - Aura Sync
    - Fan Xpert 4 (with AI Cooling II)
    - Two-Way AI Noise Cancelation
    - Power Saving
    AI Suite 3
    - TurboV EVO
    - DIGI+ VRM
    - PC Cleaner
    TUF GAMING CPU-Z
    DTS Audio Processing
    MyAsus
    Norton 360 for Gamers
    WinRAR
    UEFI BIOS
    ASUS EZ DIY
    - ASUS CrashFree BIOS 3
    - ASUS EZ Flash 3
    - ASUS UEFI BIOS EZ Mode

  • سایر توضیحات بایوس

    192 (128+64) Mb Flash ROM, UEFI AMI BIOS
