مادربرد ایسوس مدل TUF GAMING H570-PRO

305x244x60 میلی‌متر

ATX

یک عدد

Intel LGA 1200

Intel H570

10 فاز

11th Gen Intel Core Processors 10th Gen Intel Core Pentium Gold and Celeron Processors Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0 Intel Turbo Boost Max Technology 3.0 support depends on the CPU types

چهار عدد

چهار عدد

128 گیگابایت

DDR4 5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3333(OC)/3200/2933/2800/2666/2400/2133 مگاهرتز

5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3333(OC)/3200/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory Non-ECC, Un-buffered Memory Dual Channel Memory Architecture Supports Intel Extreme Memory Profile (XMP) OptiMem II 11th Gen Intel processors support 3200/2933/2800/2666/2400/2133 natively 10th Gen Intel Core i7/i9 processors support 2933/2800/2666/2400/2133 natively, others will run at the maximum transfer rate of DDR4 2666MHz

دو عدد

20 مسیر

1 مسیر PCIe 4.0/3.0 x16 slot 1 مسیر PCIe 3.0 x16 slot (supports x4 mode)

1 عدد DisplayPort 1.4 1 عدد HDMI 2.0 Graphics specifications may vary between CPU types Intel 11th & 10th processors support DisplayPort 1.4 with max. resolution of 4096 x 2304 @60Hz Only Intel 11th processors, support HDMI 2.0 with max. resolution of [email protected], others would only support HDMI 1.4 with max. resolution of [email protected]

سه عدد

شش عدد

سه عدد

PCI-E 3.0 x4 , SATA 3.0 , Key M

6 عدد

کانکتور برق اصلی 24 پبن ATX , کانکتور برق 8 پین ATX , هدر برق فن پردازنده

1 مسیر PCIe 4.0/3.0 x16 slot 1 مسیر PCIe 3.0 x16 slot (supports x4 mode) 3 مسیر PCIe 3.0 x1 slots

دو عدد

یک عدد

یک عدد

1 عدد USB 3.2 Gen 1 connector (suppports USB Type-C) 1 عدد USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 2 عدد USB 2.0 headers support additional 4 USB 2.0 ports 1 عدد Thunderbolt 4 header 1 عدد 4pin CPU Fan header 1 عدد 4pin CPU OPT Fan header 1 عدد 4pin AIO Pump header 3 عدد 4pin Chassis Fan headers 2 عدد AURA Addressable Gen 2 headers 2 عدد AURA RGB headers 1 عدد Clear CMOS header 1 عدد COM Port header 1 عدد Front Panel Audio header (AAFP) 1 عدد 20/3pin System Panel header with Chassis intrude functionpasting 1 عدد Thunderbolt header

چهار عدد

یک عدد

دو عدد

یک عدد

یک عدد

Realtek 2.5Gb

1 عدد Realtek 2.5Gb Ethernet

Realtek ALC S1200A 7.1 Surround Sound High Definition Audio CODEC

7.1 کانال

5 عدد

Realtek ALC S1200A 7.1 Surround Sound High Definition Audio CODEC پشتیبانی از Jack-detection, Multi-streaming, Front Panel Jack-retasking قابلیت پشتیبانی تا 24-Bit/192 kHz playback Audio Shielding Rear optical S/PDIF out port Premium Japanese audio capacitors Dedicated audio PCB layers Audio cover

پنل پشتی: 1 عدد USB 3.2 Gen 2x2 port (1 x USB Type-C) 2 عدد USB 3.2 Gen 2 ports (2 x Type-A) 1 عدد USB 3.2 Gen 1 port (1 x Type-A) 4 عدد USB 2.0 ports (4 x Type-A) اتصالات داخلی: 1 عدد USB 3.2 Gen 1 connector (suppports USB Type-C) 1 عدد USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 2 عدد USB 2.0 headers support additional 4 USB 2.0 ports

1 عدد USB 3.2 Gen 2x2 port (1 x USB Type-C) 2 عدد USB 3.2 Gen 2 ports (2 x Type-A) 1 عدد USB 3.2 Gen 1 port (1 x Type-A) 4 عدد USB 2.0 ports (4 x Type-A) 1 عدد DisplayPort 1 عدد HDMI port 1 عدد Realtek 2.5Gb Ethernet port 5 عدد Audio jacks 1 عدد Optical S/PDIF out port

ASUS TUF PROTECTION DIGI+ VRM (- Digital power design with DrMOS) Enhanced DRAM Overcurrent Protection TUF LANGuard Overvoltage Protection ASUS Q-Design M.2 Q-Latch Q-DIMM Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) Q-Slot ASUS Thermal Solution M.2 heatsink VRM heatsink design ASUS EZ DIY ProCool Pre-mounted I/O shield SafeSlot AURA Sync AURA RGB headers Addressable Gen 2 RGB headers Software Features ASUS Exclusive Software Armoury Crate AURA Creator AURA Sync Two-Way AI Noise Cancelation AI Suite 3 Performance And Power Saving Utility TurboV EVO EPU DIGI+ VRM Fan Xpert 4 EZ update TUF GAMING CPU-Z AI Charger ASUS Turbo LAN DAEMON Tools DTS Custom for GAMING Headsets MyASUS Norton Anti-virus software (Free Trial version) WinRAR UEFI BIOS ASUS EZ DIY ASUS CrashFree BIOS 3 ASUS EZ Flash 3 ASUS UEFI BIOS EZ Mode

2 کابل SATA 6Gb/s 2 عدد M.2 Rubber Packages 2 عدد M.2 SSD screw packages 1 عدد TUF Gaming sticker 1 عدد Support DVD 1 عدد TUF Certification card 1 عدد User manual

WOL by PME, PXE

192 (64+128) مگابایت Flash ROM UEFI AMI BIOS

DDR4 5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3333(OC)/3200/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory
