اگر بدنبال یک مادر برد هستید که پردازنده های نسل 10 و 11 اینتل بهترین عملکرد را روی آن داشته باشند باید به شما مادربرد ایسوس مدل Prime H510M-E را پیشنهاد کنم. این مادربرد با داشتن ابزار های انعطاف پذیر برای تنظیم همه جنبه های سیستم به شما امکان تنظیمات آسان و دلخواه شما را می دهد.
microATX
Intel H510
Intel LGA 1200
RAM Slot x 2
ناموجود
226x211 میلیمتر
microATX
1 عدد
Intel LGA 1200
H510
Intel 11th Gen Intel Core Processors & 10th Gen Intel Core, Pentium Gold and Celeron Processors
ندارد
2 عدد
دو کاناله
64GB
2xDIMM, Max. 64GB, DDR4 3200(OC)/ 2933/ 2800/ 2666/ 2400/ 2133 MHz Non-ECC, Un-buffered Memory
Dual Channel Memory Architecture
Supports Intel Extreme Memory Profile (XMP)
10th Gen Intel Core i7/ i9 processors support 2933/ 2800/ 2666/ 2400/ 2133 natively, others will run at the maximum transfer rate of DDR4 2666MHz.
11th Gen Intel processors support 2933/ 2800/ 2666/ 2400/ 2133 natively.
دارد
ندارد
Supports Intel Extreme Memory Profile (XMP)
10 th Gen Intel Core i7/ i9 processors support 2933/ 2800/ 2666/ 2400/ 2133 natively, others will run at the maximum transfer rate of DDR4 2666MHz.
11th Gen Intel processors support 2933/ 2800/ 2666/ 2400/ 2133 natively .
Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists), and memory frequency support depends on the CPU types.
1 عدد
ندارد
ندارد
1xDisplayPort 1.4
1xD-Sub
1xHDMITM 2.0
Graphics specifications may vary between CPU types
Intel 11th & 10th Gen processors support DisplayPort 1.4 with max resolution of 4096 x 2304 @60Hz
2 عدد
1 عدد
M.2 slot (Key M), type 2242/ 2260/ 2280 (supports PCIe 3.0 x4 & SATA modes)
ندارد
2 عدد
1x4-pin CPU Fan header
1x4-pin Chassis Fan header
2 عدد
1x24-pin Main Power connector
1x8-pin +12V Power connector
2 عدد
1 عدد
1x RGB header
1x Clear CMOS header
1x COM Port header
1x Front Panel Audio header (AAFP)
1x S/PDIF Out header
1x Speaker header
1x SPI TPM header (14-1pin)
1x 10-1 pin System Panel header
4 عدد
دو عدد / 1 عدد برای موس / 1 عدد برای کیبورد
2 عدد
2 عدد
ندارد
دارد
دارد
دارد
دارد
1x Intel I219-V 1Gb Ethernet
ندارد
ندارد
Realtek ALC897/887 7.1 Surround Sound High Definition Audio CODEC
7 کانال
3 عدد
ندارد
ندارد
Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
Supports up to 24-Bit/192 kHz playback
Audio Features:
Audio Shielding
Premium Japanese audio capacitors
Dedicated audio PCB layers
A chassis with an HD audio module in the front panel is required to support 7.1Surround Sound audio output
Rear USB (Total 4 ports)
2x USB 3.2 Gen 1 ports (2 x Type-A)
2x USB 2.0 ports (2 x Type-A)
Front USB (Total 6 ports)
1x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
2x USB 2.0 headers support additional 4 USB 2.0 ports
128Mb Flash ROM, UEFI AMI BIOS
ASUS 5X PROTECTION III:
DIGI+ VRM
LANGuard
Overvoltage Protection
SafeSlot Core
Stainless-Steel Back I/O
ASUS Q-Design:
Q-DIMM
Q-Slot
ASUS Thermal Solution:
Aluminum heatsink design
ASUS Lighting Control:
RGB header
2x SATA 6Gb/s cables
1x I/O Shield
1x M.2 SSD screw package
1x Support DVD
1x User manual
WOL by PME, PXE
ASUS EZ DIY
ASUS CrashFree BIOS 3
ASUS EZ Flash 3
ASUS UEFI BIOS EZ Mode
