مادربرد ایسوس مدل PRIME B760-PLUS یک مادربرد Intel B760 LGA 1700 ATX با پشتیبانی از PCIe 5.0 و سه سوکت PCIe 4.0 M.2 و حافظه DDR5 و Ethernet Realtek 2.5Gb و DisplayPort و VGA و HDMI و SATA 6 Gbps و USB 3.2 Gen 2x2 Type-C و USB 3.2 Gen 1 Type-C و پشتیبانی از Thunderbolt (USB4) است. این مادربرد برای پردازنده های 13th و 12th Gen Intel آماده شده است و برای سیستم های دسکتاپ با این پردازنده ها مناسب است.
ATX
Intel B760
Intel LGA 1700
RAM Slot x 4
ناموجود
244X305 میلیمتر
ATX
1 عدد
Intel LGA 1700
B760
Intel Socket LGA1700 for 13th Gen Intel Core & 12th Gen Intel Core, Pentium Gold and Celeron Processors
SATA RAID 0,1,5,10
4 عدد
دو کاناله
192GB
DDR5
دارد
ندارد
4xDIMM, Max. 192GB, DDR5 7200+(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/ 5200/ 5000/ 4800 Non-ECC, Un-buffered Memory*
Dual Channel Memory Architecture
Supports Intel Extreme Memory Profile (XMP)
OptiMem II
* Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/ Memory Support under the Support tab or visit https:/ / www.asus.com/ support/ .
* Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.
2 عدد
Intel 13th & 12th Gen Processors
1xPCIe 5.0 x16 slot
Intel B760 Chipset
1xPCIe 4.0 x16 slot (supports x4 mode)
ندارد
ندارد
1xDisplayPort**
1xVGA port
1xHDMI port***
* Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.
** Supports max. 4K@60Hz as specified in DisplayPort 1.4.
*** Supports 4K@60Hz as specified in HDMI 2.1.
2 عدد
2xPCIe 3.0 x1 slots
3 عدد
Key M
1 عدد
5 عدد
1x4-pin CPU Fan header
1x4-pin AIO Pump header
3x4-pin Chassis Fan headers
2 عدد
1x24-pin Main Power connector
1x8-pin +12V Power connector
2 عدد
2 عدد
1xUSB 3.2 Gen 1 connector (supports USB Type-C)
1xUSB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports
3xAddressable Gen 2 headers
1xAura RGB header
1xClear CMOS header
1xCOM Port header
1xFront Panel Audio header (AAFP)
1xS/PDIF Out header
1xSPI TPM header (14-1pin)
1x20-3 pin System Panel header with Chassis intrude function
4 عدد
2 عدد
1 عدد
2 عدد
1 عدد
1 عدد
1 عدد
1 عدد
1 عدد
Realtek 2.5Gb Ethernet
Realtek 7.1 Surround Sound High Definition Audio CODEC*
7.1 کانال
3 عدد
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192 kHz playback
Audio Features
- Audio Shielding
- Premium audio capacitors
- Dedicated audio PCB layers
* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
1xVertical M.2 slot (Key E)
128 Mb Flash ROM, UEFI AMI BIOS
Overvoltage Protection
ASUS 5X PROTECTION III
-DIGI+ VRM
-LANGuard
-Overvoltage Protection
-SafeSlot Core+
-Stainless-Steel Back I/O
ASUS Q-Design
-Q-DIMM
-Q-LED Core
-Q-Slot
ASUS Thermal Solution
-M.2 heatsink
-VRM heatsink design
ASUS EZ DIY
-ProCool
Aura Sync
-Aura RGB header
-Addressable Gen 2 headers
Software Features
ASUS Exclusive Software
Armoury Crate
-Aura Creator
-Aura Sync
-Fan Xpert 2+
-Power Saving
AI Suite 3
-DIGI+ VRM
-PC Cleaner
ASUS CPU-Z
Norton 360 Deluxe (60 Days Free Trial)
WinRAR
Operating System
Windows 11, Windows 10 64-bit
WOL by PME, PXE
UEFI BIOS
ASUS EZ DIY
-ASUS CrashFree BIOS 3
-ASUS EZ Flash 3
-ASUS UEFI BIOS EZ Mode
